Oxford FS Easytrack Gantry

Read all reviews
VAT Exempt
Oxford FS Easytrack Gantry

Oxford FS Easytrack Gantry

Read all reviews
£1,410.00 with VAT relief
£1,692.00 Including VAT
  • Model
  • VOY-9720010K_2284

Description:

Oxford FS Easytrack Gantry

The Easytrack FS is a lightweight, free standing overhead track system. The Easytrack FS does not rely on support from the ceiling taking away any potential structural issues that may have previously been encountered. To be used with Oxford Portable Voyger.

Key Features:
  • Easy to assemble.
  • Telescopic adjustment for ease of use.
  • Lightweight components for ease of transportability and storage.

Easy To Assemble
  • Line up each upright post with the relevant footplate and insert. The posts are self locating and require no additional tools or fixings.
  • Position the track into the fixing clips at the top of each post.
  • Lock the track in place using the clips.
  • Adjust the height of the track as necessary. The telescopic posts are sprung loaded to ensure minimal effort is required.
  • Attach the Voyager portable unit and your system is ready for use.
  • Voyger unit to be purchased separatly.

Specifications:
  • Floor to top of rail: 1830mm - 2406mm (72" - 94")
  • Floor to bottom of rail: 1680mm - 2256mm (66" - 88")
  • Exterior width: 2210mm - 3230mm (87" - 127")
  • Interior width: 1910mm - 2930mm (75" - 115")
  • Footplate length: 1075mm (42")
  • Footplate width: 150mm (6")
  • Weight of Voyager Unit including battery: 5.5kg (12lb)
  • Weight of footplate (each): 5.5kg (12lb)
  • Weight of Upright post: 9.5kg (21lb)
  • Track/Rail: 14kg (31lb)
  • Maximum user weight limit: 200kg (30st)
